80kW Cattle & Horse Veterinary DR X-ray Machine

80kW Cattle & Horse Veterinary DR X-ray Machine

Pinpoint Digestive Foreign Bodies in Cattle, Horses &Sheep;We sell directly to you, eliminating middleman margins to significantly reduce your procurement and maintenance costs.

The preferred equipment for modern veterinary hospitals, large-scale ranches, and pharmaceutical companies to enhance diagnostic capabilities.

Configuration Options

1. Floor-rail tube column + vertical bucky stand + floating table

The standard small-and-large-animal room. Full coverage of standing and recumbent patients in one suite.

2. Dual-track chest stand with auto-tracking tube

Purpose-built for equine and bovine work. The tube head follows the chest stand, so lateral and AP projections are re-positioned in seconds — ideal for stall-side or stocks-based standing exams.

3. Ceiling-suspended tube + vertical bucky + table

Nothing on the floor, any beam angle, easiest movement around a large animal. Preferred by referral hospitals and teaching facilities.

4. U-gantry dual-rail configuration

Tube and detector locked in fixed geometry and travelling together on dual rails. Repeatable SID and angle with no realignment between exposures — suited to high-volume survey and herd-health work.

Restraint stocks can be supplied with configurations 2 and 3.

Clinical Applications

• Equine thoracic, abdominal and skeletal radiography in the standing horse

• Equine distal-limb and laminitis studies with horizontal-beam technique

• Bovine thoracic, abdominal and limb imaging; foreign-body and reticuloperitonitis screening

• Pre-purchase and insurance examinations

• Orthopaedic pre-operative planning and post-operative review

• Large-breed canine and exotic-megafauna imaging in zoos and wildlife centres

• Teaching-hospital and research protocols requiring reproducible projection geometry

FAQ

Q: What room size does this system need?

A: It depends on the configuration. A floor-rail column with table typically needs 4.5 × 3.5 m of clear floor; a ceiling-suspended suite needs a slightly larger footprint and adequate ceiling structure. Send us your dimensions and we will confirm the layout.

Q: Can it run on single-phase power?

A: No. An 80 kW generator requires a three-phase 380 V supply. Please confirm your site’s available capacity; a step-up transformer or generator set can be quoted if needed.

Q: Is 80 kW overkill for a small-animal practice?

A: If you only image cats and small dogs, a 32 kW or 50 kW system is more economical. 80 kW / 1000 mA is specified for large-breed dogs, horses, cattle and zoo animals, where penetration and short exposure time are the limiting factors.

Q: Can I upgrade an existing X-ray room?

A: Often yes. If the generator and tube are in good condition, we can quote a detector-plus-workstation retrofit; if not, the full system is the more reliable route. Share photos of the current installation and we will advise.

Q: Do you support OEM/ODM and private label?

A: Yes. Enclosure branding, software language, voltage/frequency variants and packaging can be customized. Minimum order quantity and lead time depend on the configuration.

Q: What is the lead time?

A: Typically 25–45 days after deposit, depending on configuration and detector availability. Sea freight is standard; air freight is available for urgent projects.

Request a Quote

Tell us four things and we will come back with a configuration and a delivered price:

1. Animal types and typical body weight

1. Available room dimensions and power supply

1. Preferred configuration (column / ceiling / chest stand / gantry)

1. Detector preference (wired or wireless, CsI or GOS)

Send your requirements now — our engineering team replies within one working day with a layout drawing and itemized quotation.
