‌Portable Wheelless Tripod Vertical Chest Bucky Stand for Field Rescue

For Field Rescue & Emergency Radiography

The NK17SGX portable vertical chest bucky stand is a purpose-built lightweight radiography solution designed for off-site emergency scenarios. Weighing only 5.5kg with a fully foldable frame, it delivers stable, diagnostic-grade imaging performance without relying on fixed hospital infrastructure. It is the ideal backup unit for radiology departments, and a must-have piece of kit for field rescue teams, disaster relief medical units and mobile health screening programs.



















Core Compatibility

No need to replace your existing imaging hardware to use this stand. The precision-engineered wide slot supports all mainstream radiography media on the market:

• 17″×17″ and 14″×17″ traditional X-ray cassettes
• Standard CR IP plates
• All common wireless DR flat panel detectors
• Maximum supported thickness of inserted media: ≤ 29mm

This full compatibility allows medical teams to carry their existing portable X-ray generators and detectors directly to the field, without purchasing extra dedicated accessories for outdoor imaging missions.



---

Exact Structural Parameters

Parameter	Specification
Model Number	NK17SGX
Vertical Lifting Travel	Approx. 80cm
Maximum Height of Cassette Top Edge	2000mm
Minimum Height of Cassette Bottom Edge	800mm
Folded Total Height	100cm
Net Weight	5.5kg
Included Accessory	Heavy-duty dedicated carry bag



The 80cm full travel covers radiography needs for patients of different heights, from pediatric cases to adults up to 190cm tall, supporting routine imaging for chest, abdomen, pelvis and limb sites.
